Kaeser KC centrifugal separators remove condensate at the compressor's compressed air discharge point. They're a must for faultless and energy-efficient functioning of downstream dryers and filters. KC centrifugal separators are equipped with the economical and extremely reliable ECO-DRAIN 31 condensate drain – naturally, with test button and alarm contact included. They're also very easy to combine with KAESER FILTERS and can be wall-mounted using optional wall mounts – for highly straightforward installation.
Separation rates up to 99 % in the flow rate range of 0.9 to 14.2 m³/min
designed for working pressures up to 16 bar
with ECO-DRAIN 31 electronic condensate drain
- with optional wall mounts
Models with flow rates up to 88.5 m³/min, special product variants available in silicon-free design, for working pressure of 45 bar.
Kaeser has optimised the air flow in the KC centrifugal separator using the most advanced flow simulations and measured it as per ISO 12500-4. The results: a swirl insert with an excellent separation rate of up to 99 % – stable over a broad output range and with pressure loss of less than 0.1 bar.
Durable and value-retaining
With a seawater-resistant aluminium enclosure and an additional passivation coating, our centrifugal separators are built to keep on running. The compressed air connections on the enclosure are thus always a perfect fit for our rotary screw compressors.
Kaeser KC centrifugal separators are maintenance-free. Furthermore, the ECO-DRAIN condensate drain is equipped with a service module for highly reliable maintenance.
The perfect partner: the AQUAMAT oil/water separator
Our tip: Take advantage of cost-effective, legally-compliant treatment of condensate before drainage into the regular wastewater system with AQUAMAT oil/water separators.
